HOME -> PRODUCT -> INNOLUX LCD PANEL -> 10.2 inchAT102TN03 V.9
AT102TN03 V.9
Brand: CHIMEI INNOLUX
Panel Model: AT102TN03 V.9
Interface: TTL
Panel size: 10.2
Resolution: 800X3(RGB)X480
Brightness: 250
Contrast Ratio: 500:1
Display Color: 16.7M(8-bit)
Back light: WLED
Brand: group a (INNOLUX)
Panel type: AT102TN03 v. 9
Panel type: a - Si TFT - LCD, the LCD panel
Panel size: 10.2 "(inches)
Resolution: 800 X 3 X 480 (RGB)
Display mode: TN, often white display, transmission type
Surface treatment: spray surface
Panel brightness: 250 CD/m2
For than degrees: 500:1 (Typ.)
Display color: 262 k / 16.2 M (6 - bit / - bit + Dithering)
Response time: 10/15 (Typ.) (Tr/Td)
Visual Angle: 70/70/50/70 (Typ.) (CR 10 or higher) (left/right/up/down)
Lamp type: 3 s11p WLED
The signal type: TTL (1 ch, 6/8 - bit)
Panel voltage: 17.0/3.3/10.4 / - 5.0 V (Typ.) (DVDD/AVDD/VGH/VGL)
Applications: industrial
Distance: 0.0642 (W) x 0.1790 (H)
