AT043TN25V.2
| Brand： | CHIMEI INNOLUX |
| Panel Model： | AT043TN25V.2 |
| Interface： | TTL |
| Panel size： | 4.3 |
| Resolution： | 480X3(RGB)X272 |
| Brightness： | 500 |
| Contrast Ratio： | 500:1 |
| Display Color： | 16.7M(8-bit) |
| Back light： | WLED |
Brand: chi mei (CHIMEI INNOLUX)
Panel type: AT043TN25 v. 2
Panel type: a - Si TFT - LCD, the LCD panel
Panel size: 4.3 "(inches)
Resolution: 480 x 272 (RGB)
Display mode: TN, often white display, transmission type
Surface treatment: spray surface
Panel brightness: 500 CD/m2
For than degrees: 500:1 (Typ.)
Display color: 16.7 M (8-bit)
Response time: 10/15 (Typ.) (Tr/Td)
Visual Angle: 70/70/50/70 (Typ.) (CR 10 or higher) (left/right/up/down)
Lamp type: 8 s1p WLED
The signal type: the Parallel RGB (1 ch, 8-bit)
Panel voltage: 3.3 V (Typ.)
Application products: MP4, PMP portable navigator, apple TV
Distance: 0.0642 (W) x 0.1790 (H)
Panel type: AT043TN25 v. 2
Panel type: a - Si TFT - LCD, the LCD panel
Panel size: 4.3 "(inches)
Resolution: 480 x 272 (RGB)
Display mode: TN, often white display, transmission type
Surface treatment: spray surface
Panel brightness: 500 CD/m2
For than degrees: 500:1 (Typ.)
Display color: 16.7 M (8-bit)
Response time: 10/15 (Typ.) (Tr/Td)
Visual Angle: 70/70/50/70 (Typ.) (CR 10 or higher) (left/right/up/down)
Lamp type: 8 s1p WLED
The signal type: the Parallel RGB (1 ch, 8-bit)
Panel voltage: 3.3 V (Typ.)
Application products: MP4, PMP portable navigator, apple TV
Distance: 0.0642 (W) x 0.1790 (H)
